•  Date Published: 26 Sep 2022
  • AMD Ryzen 5 5600H
  • AMD Radeon RX Vega 7 (R4000,5000 35/45W)
  • 15.6″, 2.8K (2880 x 1620), 120 Hz, OLED
  • 512GB SSD
  • 2x 8GB DDR4
  • 1.80 kg (4 lbs)

Pros

  • Adequate pricing
  • Decent performance
  • 100% sRGB and DCI-P3 coverage (Samsung ATNA56AC01-0 (SDC416E))
  • HDR True Black 500 support and infinite contrast ratio (Samsung ATNA56AC01-0 (SDC416E))
  • 120Hz refresh rate with blazingly quick pixel response times
  • Optional Wi-Fi 6 and fingerprint reader
  • Great battery life

Cons

  • PWM usage (Samsung ATNA56AC01-0 (SDC416E))
  • Uses USB Type-A 2.0
  • The cooling is not spectacular

Specs

CPU Performance #46in Top CPUs
  • Intel Core i7-10875H 1.1%
  • AMD Ryzen 7 5800U 0.5%
  • AMD Ryzen 5 5600H
  • AMD Ryzen 7 5850U 0.8%
  • Intel Core i7-1270P 0.1%
  • Intel Core i7-10870H 1.1%
GPU Performance #101in Top GPUs
  • NVIDIA GeForce MX250 (25W) 0.6%
  • NVIDIA GeForce MX350 (25W) 2.1%
  • AMD Radeon RX Vega 7 (R4000,5000 35/45W)
  • NVIDIA GeForce MX330 (4GB GDDR5, 25W)
  • NVIDIA GeForce MX330 (2GB GDDR5, 25W) 0.2%
  • NVIDIA Quadro P520 (4GB GDDR5) 1.2%
  • Samsung ATNA56AC01-0 (SDC416E)
  • Color accuracy  3.4  3.2
  • HDD/SSD
  • 512GB SSD
  • RAM
  • 2x 8GB DDR4
  • OS
  • Windows 11 Home
  • Body Material
  • Plastic / Polycarbonate, Aluminum
  • Dimensions
  • 359.8 x 232.9 x 18.9 mm (14.17" x 9.17" x 0.74")
  • Weight
  • 1.80 kg (4 lbs)
  • Ports and connectivity
  • 1x USB Type-A
  • 2.0
  • 1x USB Type-A
  • 3.2 Gen 1 (5 Gbps)
  • 2x USB Type-C
  • 3.2 Gen 2 (10 Gbps), Power Delivery (PD), DisplayPort
  • HDMI
  • 2.0
  • Card Reader
  • Ethernet LAN
  • Wi-Fi
  • 802.11ax
  • Bluetooth
  • 5.0
  • Audio jack
  • 3.5mm Combo Jack
  • Features
  • Fingerprint reader
  • Web camera
  • HD with privacy shutter
  • Backlit keyboard
  • Microphone
  • Array Microphone with Cortana and Alexa voice rec.
  • Speakers
  • Speakers by Harman Kardon, Smart Amp
  • Optical drive
  • Security Lock slot

More ASUS VivoBook S 15 OLED (M3502) configurations - 1 laptops

#CommissionsEarned

DISPLAY: 15.6-inch, 2880x1620, OLED

  • Name
  • Samsung ATNA56AC01-0 (SDC416E)
  • Diagonal
  • 15.6"
  • Pixel density
  • 211.82 ppi
  • Brightness
  • 401 cd/m2
  • sRGB
  • 100%
  • PWM frequency
  • 238 Hz
  • Panel Type
  • OLED
  • Resolution
  • 2880x1620
  • Becomes "Retina" from
  • 16 inches (41 cm)
  • Contrast
  • infinite
  • dE Color Checker
  • 3.4 3.2
  • PWM Rating
  • 4.8: (undesirable)

Buy our profiles for Samsung ATNA56AC01-0 (SDC416E)

In addition to receiving efficient and health-friendly profiles, by buying LaptopMedia's products you also support the development of our labs, where we test devices in order to produce the most objective reviews possible.

Office Work

Office Work should be used mostly by users who spend most of the time looking at pieces of text, tables or just surfing. This profile aims to deliver better distinctness and clarity by keeping a flat gamma curve (2.20), native color temperature and perceptually accurate colors.

Design and Gaming

This profile is aimed at designers who work with colors professionally, and for games and movies as well. Design and Gaming takes display panels to their limits, making them as accurate as possible in the sRGB IEC61966-2-1 standard for Web and HDTV, at white point D65.

Health-Guard

Health-Guard eliminates the harmful Pulse-Width Modulation (PWM) and reduces the negative Blue Light which affects our eyes and body. Since it’s custom tailored for every panel, it manages to keep the colors perceptually accurate. Health-Guard simulates paper so the pressure on the eyes is greatly reduced.

Get all 3 profiles with 33% discount

ASUS VivoBook S 15 OLED (M3502) in-depth review

We live in a world, where laptops get more expensive. The main reason for that is the modern practice of new CPUs being released every year. But at some point, the upgrades were poised to become only incremental. This is what happened with AMD this year (at least regarding the computational performance). Essentially, this paves the way for Ryzen 5000H devices to become best-sellers again, due to their lower price. The VivoBook S 15 OLED (M3502) is one such notebook. It has a youthful vibe, paired with pretty capable hardware, and - as the name suggests, a display to die for. You still have the option to choose between two configurations - a 1080p panel with 600 nits HDR peak brightness, full DCI-P3 color coverage, True Blacks, and a 60Hz refresh rate or ... or 2880 by 1620p 120Hz unit [...]

Read the full review

Disassembly, maintenance and upgrade options

Due to the older chipset, the Vivobook S 15 OLED (UM3502) only supports Gen 3 SSDs. Check out all ASUS Vivobook S 15 OLED (UM3502) prices and configurations in our Specs System, or read more in our In-Depth review. 1. Remove the bottom plate To get inside this notebook, you need to undo 10 Torx-head screws. Then, pry the bottom panel with a plastic tool, and carefully lift it away from the chassis. 2. Battery Here, we find a 70Wh battery pack. It lasts for 16 hours and 30 minutes of Web browsing, or more than 10 hours of video playback. To take it out, you need to unplug the[...]

Read more

CPU Performance: AMD Ryzen 5 5600H

GPU Performance: AMD Radeon RX Vega 7 (R4000,5000 35/45W)

Some games you can play on this laptop

Resolution: 1920 x 1080 (Full HD)
HIGH PERF
HIGH QLT
AMD Radeon RX Vega 7 (R4000,5000 35/45W) 135 FPS PLAY VIDEO 46 FPS PLAY VIDEO
