日本ASUS TUF Gaming F17
 47.jpg)
- Date Published: 30 Sep 2021
- Intel Core i5-11260H
- NVIDIA GeForce RTX 3050 Ti (Laptop, 75W)
- 17.3”, Full HD (1920 x 1080), 144 Hz, IPS + FreeSync
- 512GB SSD
- 8GB DDR4, 3200 MHz
- 2.60 kg (5.7 lbs)
Pros
- Tough chassis
- 2x SODIMM + 2x M.2 PCIe x4 (one of which supports Gen 4 SSDs)
- 144Hz refresh rate (AUO B173HAN04.9)
- No PWM (AUO B173HAN04.9)
- Thunderbolt 4 + HDMI 2.0b (G-Sync)
- Adaptive Sync support (AUO B173HAN04.9)
- Great battery life for a gaming laptop
Cons
- No SD card reader
- Covers only 51% of sRGB (AUO B173HAN04.9)
Specs
- HDD/SSD
- 512GB SSD
- M.2 Slot
- 1x 2280 M.2 PCIe 4.0 x4 + 1x 2280 M.2 PCIe 3.0 x4 See photo
- RAM
- 8GB DDR4, 3200 MHz
- OS
- Windows 10 Home
- Body Material
- Plastic / Polycarbonate, Aluminum
- Dimensions
- 399 x 269 x 23.9 ~ 24.8 mm (15.71" x 10.59" x 0.94")
- Weight
- 2.60 kg (5.7 lbs)
- Ports and connectivity
- 3x USB Type-A
- 3.2 Gen 1 (5 Gbps)
- 1x USB Type-C
- Thunderbolt 4, DisplayPort
- HDMI
- 2.0b
- Card Reader
- Ethernet LAN
- Wi-Fi
- 802.11ax
- Bluetooth
- 5.2
- Audio jack
- 3.5mm Combo Jack
- Features
- Fingerprint reader
- Web camera
- HD
- Backlit keyboard
- Microphone
- Array Microphone with AI Noise Cancelling
- Speakers
- 2x 2W, DTS: X Ultra
- Optical drive
- Security Lock slot
- Kensington Lock
There are 2 laptops with the same specs, All brands (sorted by price)
More ASUS TUF Gaming F17 configurations - 126 laptops
DISPLAY: 17.3-inch, 1920x1080, IPS + FreeSync
- Name
- AUO B173HAN04.9 (AUO978F)
- Diagonal
- 17.3"
- Pixel density
- 127.34 ppi
- Brightness
- 281 cd/m2
- sRGB
- 50%
- PWM frequency
- No PWM (Flicker-Free)
- Panel Type
- IPS
- Resolution
- 1920x1080
- Becomes "Retina" from
- 27 inches (69 cm)
- Contrast
- 1220:1
- dE Color Checker
- 4.6 3.8
- PWM Rating
- 10.0: (safe)
Buy our profiles for AUO B173HAN04.9 (AUO978F)
In addition to receiving efficient and health-friendly profiles, by buying LaptopMedia's products you also support the development of our labs, where we test devices in order to produce the most objective reviews possible.
Office Work
Office Work should be used mostly by users who spend most of the time looking at pieces of text, tables or just surfing. This profile aims to deliver better distinctness and clarity by keeping a flat gamma curve (2.20), native color temperature and perceptually accurate colors.
Design and Gaming
This profile is aimed at designers who work with colors professionally, and for games and movies as well. Design and Gaming takes display panels to their limits, making them as accurate as possible in the sRGB IEC61966-2-1 standard for Web and HDTV, at white point D65.
Health-Guard
Health-Guard eliminates the harmful Pulse-Width Modulation (PWM) and reduces the negative Blue Light which affects our eyes and body. Since it’s custom tailored for every panel, it manages to keep the colors perceptually accurate. Health-Guard simulates paper so the pressure on the eyes is greatly reduced.
Get all 3 profiles with 33% discount
ASUS TUF Gaming F17 in-depth review
It wasn't long ago before we showed you the ASUS TUF Gaming F17 FX706. However, like many other manufacturers, ASUS itself has released facelifts of some of its most popular laptops. Including the FX706. Generally, it looks pretty similar, but it brings a lot of new hardware. Since it was released in 2021, you can't expect Alder Lake chips. Nevertheless, their Tiger Lake counterparts are pretty capable in both games and productivity. What else is great for gaming and productivity is the RTX 3060 GPU, which you can find inside of it. It comes with 95W of TGP, and 6GB of GDDR6 graphics memory. As you may know, the TUF brand is all about rigidity. This explains the industrial design. To complement that, the laptop covers a set of military-grade tests, called MIL-STD-810H. Perhaps ev[...]
Read the full review
Disassembly, maintenance and upgrade options
Here, we will show you how to upgrade one of the most popular gaming laptops on the market. It is a pretty good deal for both gamers and people that need the sheer power of the hardware. Check out all ASUS TUF Gaming F17 (FX706, 2021) prices and configurations in our Specs System or read more in our In-Depth review. 1. Remove the bottom plate To take this notebook apart, you need to undo 11 Phillips-head screws. The top left one remains attached and lifts the bottom panel, which allows you to start the prying process from there. After you are done, lift the panel away from the cha[...]
Read more
CPU Performance: Intel Core i5-11260H
Results are from the Cinebench 20 CPU test (the higher the score, the better)
GPU Performance: NVIDIA GeForce RTX 3050 Ti (Laptop, 75W)
Results are from the 3DMark: Time Spy (Graphics) benchmark (higher the score, the better)
Some games you can play on this laptop
|
Resolution: 1920 x 1080 (Full HD)
|
NORMAL
|
HIGH
|
VERY HIGH
|
MAX
|
|---|---|---|---|---|
| NVIDIA GeForce RTX 3050 Ti (Laptop, 75W) | 126 FPS PLAY VIDEO | 95 FPS PLAY VIDEO | 59 FPS PLAY VIDEO | 40 FPS PLAY VIDEO |
|
Resolution: 1920 x 1080 (Full HD)
|
MIN
|
MED
|
MAX
|
|---|---|---|---|
| NVIDIA GeForce RTX 3050 Ti (Laptop, 75W) | 212 FPS PLAY VIDEO | 167 FPS PLAY VIDEO | 117 FPS PLAY VIDEO |
|
Resolution: 1920 x 1080 (Full HD)
|
LOW
|
MED
|
HIGH
|
EPIC
|
|---|---|---|---|---|
| NVIDIA GeForce RTX 3050 Ti (Laptop, 75W) | 173 FPS PLAY VIDEO | 75 FPS PLAY VIDEO | 61 FPS PLAY VIDEO | 38 FPS PLAY VIDEO |
|
Resolution: 1920 x 1080 (Full HD)
|
MIN
|
MED
|
HIGH
|
ULTRA
|
|---|---|---|---|---|
| NVIDIA GeForce RTX 3050 Ti (Laptop, 75W) | 94 FPS PLAY VIDEO | 57 FPS PLAY VIDEO | 30 FPS PLAY VIDEO | - PLAY VIDEO |
|
Resolution: 1920 x 1080 (Full HD)
|
LOW
|
MED
|
HIGH
|
ULTRA
|
|---|---|---|---|---|
| NVIDIA GeForce RTX 3050 Ti (Laptop, 75W) | 65 FPS PLAY VIDEO | 58 FPS PLAY VIDEO | 50 FPS PLAY VIDEO | 38 FPS PLAY VIDEO |
|
Resolution: 1920 x 1080 (Full HD)
|
MIN
|
MAX
|
|---|---|---|
| NVIDIA GeForce RTX 3050 Ti (Laptop, 75W) | 460 FPS PLAY VIDEO | 61 FPS PLAY VIDEO |
|
Resolution: 1920 x 1080 (Full HD)
|
LOW
|
MED
|
MAX
|
|---|---|---|---|
| NVIDIA GeForce RTX 3050 Ti (Laptop, 75W) | 442 FPS PLAY VIDEO | 380 FPS PLAY VIDEO | 309 FPS PLAY VIDEO |
|
Resolution: 1920 x 1080 (Full HD)
|
VERY LOW
|
MED
|
MAX
|
|---|---|---|---|
| NVIDIA GeForce RTX 3050 Ti (Laptop, 75W) | 354 FPS PLAY VIDEO | 347 FPS PLAY VIDEO | 313 FPS PLAY VIDEO |
|
Resolution: 1920 x 1200 (WUXGA)
|
MIN
|
MED
|
ULTRA
|
|---|---|---|---|
| NVIDIA GeForce RTX 3050 Ti (Laptop, 75W) | 450 FPS PLAY VIDEO | 269 FPS PLAY VIDEO | 132 FPS PLAY VIDEO |
|
Resolution: 1920 x 1080 (Full HD)
|
LOW
|
MED
|
HIGH
|
ULTRA
|
|---|---|---|---|---|
| NVIDIA GeForce RTX 3050 Ti (Laptop, 75W) | 83 FPS PLAY VIDEO | 68 FPS PLAY VIDEO | 41 FPS PLAY VIDEO | 41 FPS PLAY VIDEO |
