•  Date Published: 10 Feb 2022
  • Intel Core i7-12650H
  • NVIDIA GeForce RTX 3050 Ti (Laptop, 75W)
  • 15.6”, Full HD (1920 x 1080), 144 Hz, IPS + FreeSync
  • 1000GB SSD
  • 2x 8GB DDR5, 4800 MHz
  • 2.00 kg (4.4 lbs)


  • MUX switch
  • 2x SODIMM + 2x M.2 PCIe x4 (one supports Gen 4 SSDs)
  • Fast display options
  • No PWM (Innolux N156HME-GAK (CMN153C))
  • HDMI 2.0b (G-Sync)
  • Adaptive Sync support (Innolux N156HME-GAK (CMN153C))
  • Up to 9 hours of battery life
  • The Armoury Crate offers a lot of customization
  • Thunderbolt 4 connector


  • No SD card reader
  • Covers only 53% of sRGB (Innolux N156HME-GAK (CMN153C))
  • CPU has some unextracted potential


  • 1TB SSD
  • M.2 Slot
  • 1x 2280 PCIe NVMe 3.0 x4 + 1x 2280 PCIe NVMe 4.0 x4  See photo
  • RAM
  • 2x 8GB DDR5, 4800 MHz
  • OS
  • Windows 11 Home
  • Body Material
  • Aluminum
  • Dimensions
  • 354 x 251 x 19.9 - 20.7 mm (13.94" x 9.88" x 0.78")
  • Weight
  • 2.00 kg (4.4 lbs)
  • Ports and connectivity
  • 2x USB Type-A
  • 3.2 Gen 1 (5 Gbps)
  • 1x USB Type-C
  • 3.2 Gen 2 (10 Gbps), Power Delivery (PD), DisplayPort
  • 1x USB Type-C
  • Thunderbolt 4
  • HDMI
  • 2.0b
  • Card Reader
  • Ethernet LAN
  • Wi-Fi
  • 802.11ax
  • Bluetooth
  • 5.2
  • Audio jack
  • 3.5mm Combo Jack
  • Features
  • Fingerprint reader
  • Web camera
  • HD
  • Backlit keyboard
  • Microphone
  • Array Microphone with AI Noise Cancelling
  • Speakers
  • 2x Speakers, Dolby Atmos
  • Optical drive
  • Security Lock slot
  • Kensington Lock

More ASUS TUF Dash F15 configurations - 199 laptops


DISPLAY: 15.6-inch, 1920x1080, IPS + FreeSync

  • Name
  • Innolux N156HME-GAK (CMN153C)
  • Diagonal
  • 15.6"
  • Pixel density
  • 141.21 ppi
  • Brightness
  • 296 cd/m2
  • sRGB
  • 53%
  • PWM frequency
  • No PWM (Flicker-Free)
  • Panel Type
  • IPS
  • Resolution
  • 1920x1080
  • Becomes "Retina" from
  • 24 inches (62 cm)
  • Contrast
  • 1130:1
  • dE Color Checker
  • 6.6 3.9
  • PWM Rating
  • 10.0: (safe)

Buy our profiles for Innolux N156HME-GAK (CMN153C)

In addition to receiving efficient and health-friendly profiles, by buying LaptopMedia's products you also support the development of our labs, where we test devices in order to produce the most objective reviews possible.

Office Work

Office Work should be used mostly by users who spend most of the time looking at pieces of text, tables or just surfing. This profile aims to deliver better distinctness and clarity by keeping a flat gamma curve (2.20), native color temperature and perceptually accurate colors.

Design and Gaming

This profile is aimed at designers who work with colors professionally, and for games and movies as well. Design and Gaming takes display panels to their limits, making them as accurate as possible in the sRGB IEC61966-2-1 standard for Web and HDTV, at white point D65.


Health-Guard eliminates the harmful Pulse-Width Modulation (PWM) and reduces the negative Blue Light which affects our eyes and body. Since it’s custom tailored for every panel, it manages to keep the colors perceptually accurate. Health-Guard simulates paper so the pressure on the eyes is greatly reduced.

Get all 3 profiles with 33% discount

ASUS TUF Dash F15 in-depth review

The TUF - F15 was ... wait, the TUF Dash F15 was a very solid laptop last year. However, it was hindered by its 35W CPU. In fact, we are pretty sure that a lot of manufacturers were really deceived by Intel's promises. While Tiger Lake proved to be successful in general, the 35W solutions were just not good enough, due to their low core count. Looking at the specs sheet of the TUF Dash F15 FX517 (or 2022), we see that the CPU choice is once again unorthodox. Instead of going for the absolute beast Core i7-12700H, ASUS has "settled" for a Core i7-12650H. Once again limited by a low core count. Well, this is what someone would think if it hadn't had experience with the Alder Lake CPUs. Even though it sports 6 P-cores and 4 E-cores, we are pretty positive that it is going to wipe the f[...]

Read the full review

Disassembly, maintenance and upgrade options

ASUS gave the brand new TUF Dash F15 all of the goodies - dual-channel DDR5 memory, as well as two M.2 PCIe x4 Gen 4 SSD slots. Not bad at all! Check out all ASUS TUF Dash F15 FX517 prices and configurations in our Specs System or read more in our In-Depth review. 1. Remove the bottom plate This device's bottom panel is held in place by 12 Phillips-head screws. One of them is captive and lifts the corner of the panel, so you can start the prying process from there. 2. Battery Here, the battery has a capacity of 76Wh. It lasts for about 9 hours of Web browsing, or nearly 7 ho[...]

Read more

CPU Performance: Intel Core i7-12650H

Some games you can play on this laptop
